8.5. Pgpool-II on Kubernetes

8.5.4.1. Configure Pgpool-II using environment variables

Kubernetes environment variables can be passed to a container in a pod. You can define environment variables in the deployment manifest to configure Pgpool-II's parameters. pgpool-deploy-minimal.yaml is an example manifest including the minimal settings of environment variables. You can download pgpool-deploy-minimal.yaml and modify the environment variables in this manifest.

$ curl -LO https://raw.githubusercontent.com/pgpool/pgpool2_on_k8s/master/pgpool-deploy-minimal.yaml


Environment variables starting with PGPOOL_PARAMS_ can be converted to Pgpool-II's configuration parameters and these values can override the default settings.

On kubernetes, you need to specify only two backend nodes. Update pgpool-deploy-minimal.yaml based on your PostgreSQL cluster information. Specify the primary service name to backend_hostname0. Specify the replica service name to backend_hostname1. Because failover is managed by Kubernetes, specify DISALLOW_TO_FAILOVER flag to backend_flag for both of the two nodes and ALWAYS_PRIMARY flag to backend_flag0. The setiing of backend_data_directory is not required.

For example, the following environment variables defined in manifest,

env:
- name: PGPOOL_PARAMS_BACKEND_HOSTNAME0
  value: "mypostgres"
- name: PGPOOL_PARAMS_BACKEND_HOSTNAME1
  value: "mypostgres-replica"
- name: PGPOOL_PARAMS_BACKEND_FLAG0
  value: "ALWAYS_PRIMARY|DISALLOW_TO_FAILOVER"
- name: PGPOOL_PARAMS_BACKEND_FLAG1
  value: "DISALLOW_TO_FAILOVER"


will be convert to the following configuration parameters in pgpool.conf.

backend_hostname0 = 'mypostgres'
backend_hostname1 = 'mypostgres-replica'
backend_flag0 = 'ALWAYS_PRIMARY|DISALLOW_TO_FAILOVER'
backend_flag1 = 'DISALLOW_TO_FAILOVER'


Then, you need to define environment variables that contain the username and password of PostgreSQL users for client authentication. For more details see Section 8.5.5.3.

After configuring the manifest, run the following command to deploy Pgpool-II.

kubectl apply -f pgpool-deploy-minimal.yaml


8.5.4.2. Configure Pgpool-II using ConfigMap

Alternatively, you can use a Kubernetes ConfigMap to store entire pgpool.conf and pool_hba.conf. The ConfigMap can be mounted to Pgpool-II's container as a volume.

You can download the example manifest files that define the ConfigMap and Deployment from repository.

curl -LO https://raw.githubusercontent.com/pgpool/pgpool2_on_k8s/master/pgpool-configmap.yaml
curl -LO https://raw.githubusercontent.com/pgpool/pgpool2_on_k8s/master/pgpool-deploy.yaml


The manifest that defines the ConfigMap is in the following format. You can update it based on your configuration preferences. To use the pool_hba.conf for the client authentication, you need to turn on enable_pool_hba. Default is off.

apiVersion: v1
kind: ConfigMap
metadata:
  name: pgpool-config
  labels:
    name: pgpool-config
data:
  pgpool.conf: |-
    listen_addresses = '*'
    port = 9999
    socket_dir = '/var/run/pgpool'
    pcp_listen_addresses = '*'
    pcp_port = 9898
    pcp_socket_dir = '/var/run/pgpool'
    backend_hostname0 = 'postgres'
...
  pool_hba.conf: |-
    local   all         all                               trust
    host    all         all         127.0.0.1/32          trust
    host    all         all         ::1/128               trust
    hostssl all         all         0.0.0.0/0             md5


Then, you need to define environment variables that contain the username and password of PostgreSQL users for client authentication. For more details see Section 8.5.5.3.

Run the following commands to create a ConfigMap and deploy the Pgpool-II pod that references this ConfigMap.

kubectl apply -f pgpool-configmap.yaml
kubectl apply -f pgpool-deploy.yaml


After deploying Pgpool-II, you can see the Pgpool-II pod and services using kubectl get pod and kubectl get svc command.

8.5.5.1. Backend settings

On kubernetes, you need to specify only two backend nodes. Specify the primary service name to backend_hostname0, replica service name to backend_hostname1.

backend_hostname0 = '<primary service name>'
backend_hostname1 = '<replica service name>'
backend_port0 = '5432'
backend_port1 = '5432'


8.5.5.2. Automated failover

Pgpool-II has the ability to periodically connect to the configured PostgreSQL backends and check the state of PostgreSQL. If an error is detected, Pgpool-II will trigger the failover. On Kubernetes, Kubernetes monitors the PostgreSQL pods, if a pod goes down, Kubernetes will restart a new one. You need to disable Pgpool-II's automated failover, becuase Pgpool-II's automated failover is not required on Kubernetes.

Specify PostgreSQL node 0 as primary (ALWAYS_PRIMARY), because Service name doesn't change even if the primary or replica pod is sacled, restarted or failover occurred.

backend_flag0 ='ALWAYS_PRIMARY|DISALLOW_TO_FAILOVER'
backend_flag1 ='DISALLOW_TO_FAILOVER'
failover_on_backend_error = off


8.5.5.3. Register password to pool_passwd

Pgpool-II performs authentication using pool_passwd file which contains the passwords of PostgreSQL users.

At Pgpool-II pod startup, Pgpool-II automatically executes pg_md5 command to generate pool_passwd based on the environment variables defined in the format <some string>_USERNAME and <some string>_PASSWORD.

The environment variables that represent the username and password of PostgreSQL user must be defined in the following format:

username: <some string>_USERNAME
password: <some string>_PASSWORD


Define the environment variables using Secret is the recommended way to keep user credentials secure. In most PostgreSQL Operators, several Secrets which define the PostgreSQL user's redentials will be automaticlly created when creating a PostgreSQL cluster. Use kubectl get secret command to check the existing Secrets.

For example, mypostgres-postgres-secret is created to store the username and password of postgres user. To reference this secret, you can define the environment variables as below:

env:
- name: POSTGRES_USERNAME
  valueFrom:
     secretKeyRef:
       name: mypostgres-postgres-secret
       key: username
- name: POSTGRES_PASSWORD
  valueFrom:
     secretKeyRef:
       name: mypostgres-postgres-secret
       key: password


When the Pgpool-II pod is started, pool_passwd and pcp.conf are automatically generated under /opt/pgpool-II/etc.

$ kubectl exec <pgpool pod> -it -- cat /opt/pgpool-II/etc/pool_passwd
postgres:md53175bce1d3201d16594cebf9d7eb3f9d

$ kubectl exec <pgpool pod> -it -- cat /opt/pgpool-II/etc/pcp.conf
postgres:e8a48653851e28c69d0506508fb27fc5


8.5.5.4. Streaming replication check

Pgpool-II has the ability to periodically connect to the configured PostgreSQL backends and check the replication delay. To use this feature, sr_check_user and sr_check_password are required. If sr_check_password is left blank, Pgpool-II will try to get the password for sr_check_user from pool_passwd.

Below is an example that connects to PostgreSQL using postgres user every 10s to perform streaming replication check. Because sr_check_password is left blank, Pgpool-II will get the password of postgres user from pool_passwd.

sr_check_period = 10
sr_check_user='postgres'


Create the secret to store the username and password of PostgreSQL user specified in sr_check_user and configure the environment variables to reference the created Secret. In most PostgreSQL Operators, several secrets which define the PostgreSQL user's redentials will be automaticlly created when creating a PostgreSQL cluster. Use kubectl get secret command to check the existing secrets.

For example, the environment variables below reference the Secret mypostgres-postgres-secret.

env:
- name: POSTGRES_USERNAME
  valueFrom:
     secretKeyRef:
       name: mypostgres-postgres-secret
       key: username
- name: POSTGRES_PASSWORD
  valueFrom:
     secretKeyRef:
       name: mypostgres-postgres-secret
       key: password


However, on Kubernetes Pgpool-II connects to any of the replicas rather than connecting to all the replicas. Even if there are multiple replicas, Pgpool-II manages them as one replica. Therefore, Pgpool-II may not be able to properly determine the replication delay. To disable this feature, configure the following parameter:

sr_check_period = 0


8.5.5.5. SSL settings

Turn on ssl to enable the SSL connections.

ssl = on


When ssl = on, at Pgpool-II startup, private key file and certificate file will be automatically generated under /opt/pgpool-II/certs/. ssl_key and ssl_cert will be automatically configured with the path of private key file and certificate file.

In addition, to allow only SSL connections, add the following record into the pool_hba.conf. For more details on configuring pool_hba.conf see Section 8.5.4.2.

hostssl    all         all         0.0.0.0/0             md5
